ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007
Menu Structure of VS 3000
95
eckelmann.de
E 2007 - ECKELMANN AG | BERLINER STRASSE 161 | 65205 WIESBADEN | TELEFON + 49(0)611 71 03-0 | FAX +49(0)611 71 03-133
S Masque 3-1-d Enable comp.stages
ENABL.COMP. POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Comp. stage 1 XXX Condenser Stage 1 ↑, ↓
(ON/OFF)
ON ON -
... Only the available condenser stages
(as configured) are shown
Comp. stage 12 XXX Condenser Stage 12 ↑, ↓
(ON/OFF)
ON ON -
VS 3000 basic module: Capacity stage 1 - max. 4
With 1st SIOX extension module: Capacity stage 1 - max. 8
With 2nd SIOX extension module: Capacity stage 1 - max. 12
S Masque 3-1-e Enable cond.stages
ENABL.COND. POS: XXXXX Entry
Default / Dimension
NT LT Dim.
Cond. stage 1 XXX Condenser Stage 1 ↑, ↓
(ON/OFF)
ON ON -
... Only the available condenser stages
(as configured) are shown
Cond. stage 12 XXX Condenser Stage 12 ↑, ↓
(ON/OFF)
ON ON -
VS 3000 basic module: Fan 1 - max. 4
With 1st SIOX extension module: Fan 1 - max. 8
With 2nd SIOX extension module: Fan 1 - max. 12
S Menu 3-2 Control
S
e
t
p
o
i
n
t
s
P
O
S
X
X
X
X
X
E
n
t
r
y
Setpoints POS: XXXXX Entr
y
LP-Control √ Move to Menu 3-2-1 √
HP-Control Move to Menu 3-2-2 √
S Menu 3-2-1 LP-Control
LP-Control POS: XXXXX
1 Control Move to Menu 3-2-1-1
2 to-adjustment Move to Menu 3-2-1-2
3 LP-Control day Move to Menu 3-2-1.3
4 LP-Control night Move to Menu 3-2-1-4
