ECKELMANN VS 3000 User Manual

Version 2.02 15.05.2007 Pin and Terminal Assignments of VS 3000
72
Digital Intputs
Function Basic Module
Extension Module
F
u
n
c
t
i
o
n
B
a
s
i
c
M
o
d
u
l
e
Terminal No.
SIOX 1 SIOX 2
Motor overload cutout Compressor9 - - 52, 53
Motor overload cutout Compressor10 - - 56, 57
Motor overload cutout Compressor11 - - 60, 61
Motor overload cutout Compressor12 - - 64, 65
Heat recovery 90, 91 -
Load shedding Stage 1 82, 83 -
Load shedding Stage 2 84, 85 -
Emergency mode / Load shedding Stage 3 86, 87 -
Level monitoring/Refrigerant low liquid level 94, 95 -
Digital Outputs
Function Basic Module
Extension Module
F
u
n
c
t
i
o
n
B
a
s
i
c
M
o
d
u
l
e
Terminal No.
SIOX 1 SIOX 2
Enable refrigeration points 1, 2 - -
Toggle FC compressor 3, 4 - -
Controller Compressor 1 13, 14 - -
Controller Compressor 2 23, 24 - -
Controller Compressor 3 33, 34 - -
Controller Compressor 4 43, 44 - -
Controller Compressor 5 - 13, 14 -
Controller Compressor 6 - 23, 24 -
Controller Compressor 7 - 33, 34 -
Controller Compressor 8 - 43, 44 -
Controller Compressor 9 - - 13, 14
Controller Compressor 10 - - 23, 24
Controller Compressor 11 - - 33, 34
Controller Compressor 12 - - 43, 44
Controller Condenser Fan 1 15,16, 18 - -
Controller Condenser Fan 2 25, 26, 28 - -
Controller Condenser Fan 3 35, 36, 38 - -
Controller Condenser Fan 4 45, 46, 48 - -
Controller Condenser Fan 5 - 15,16, 18 -
Controller Condenser Fan 6 - 25, 26, 28 -
Controller Condenser Fan 7 - 35, 36, 38 -
Controller Condenser Fan 8 - 45, 46, 48 -
Controller Condenser Fan 9 - - 15,16, 18
Controller Condenser Fan 10 - - 25, 26, 28
Controller Condenser Fan 11 - - 35, 36, 38
Controller Condenser Fan 12 - - 45, 46, 48
