S Menu 2-4 System
SYSTEM POS: XXXXX
HP cutout XXX Digital input, HP cutout
LP cutout XXX Digital input, LP cutout
Burst disk XXX Digital input, bursting disk
Low liq. level XXX Digital input, low refrigerant level
Ext. alarm XXX Digital input, external alarm
Setp. toggle XXX Digital input, setpoint toggle
Heat recovery XXX Digital input, heat recovery
Comp/cond OFF XXX Digital input, external unload
Load shed 1 XXX Digital input, Load Shedding 1
Load shed 2 XXX Digital input, Load Shedding 2
Load shed 3 XXX Digital input, Load Shedding 3
Cons.enab.CAN. XXX Enable refrigeration point via CAN bus
Cons.enab.Rel. XXX Enable refrigeration point via digital output (only shown when interstage feed is deacti-va-
ted: Parameters Feed Temp and Feed Temp.HR (Menu 3-3) must be set to ”-”.)
Med.Press.inj. XXX Status of digital output for interstage feed (only shown when interstage feed is activated:
Minimum of one parameter Feed Temp or Feed Temp.HR (Men 3-3) must not be set to ”-”).
toggle Comp. XXX Status of digital output for base load rotation of variable-speed compressors with com-pres-
sor combined control (only shown when compressor combined control is activated: Control
Type parameter set to Combined Controller, Menu 3-2-1-1-a).
S Menu 2-5 D2D Discharge Gas Defrosting
D2D POS: XXXXX
Gem.Druckltg. XXX Output, Solenoid Valve 1 common discharge line
Abla.Heiz. Z2 XXX Output, drain heater Z2 coldrooms
Abtauung Z2 XXX Input, manual defrost Z2/Z2 cases
Abtausper. Z2 XXX Input, disable defrost Z2/Z2 cases
HD-Begr. Z2 XXX Input, HP cutout in Z1 suction line Z2/Z2 cases
Saugltg. Z2 XXX Output, Solenoid Valve 2.2/1 close suction line Z2/Z2 cases
Druckgas Z2 XXX Output, Solenoid Valve 3.2/1 feed discharge gas Z2/Z2 cases
Abtauung Z2R XXX Input, manual defrost Z2 coldrooms
Abtausper. Z2R XXX Input, disable defrost Z2 coldrooms
HD-Wächter Z2R XXX Input, HP cutout in Z1 suction line Z2 coldrooms
Saugltg. Z2R XXX Output, Solenoid Valve 2.2/2 close suction line Z2 coldrooms
Druckgas Z2R XXX Output, Solenoid Valve 3.2/2 feed discharge gas Z2 coldrooms
