Version 2.02 15.05.2007 Menu Structure of VS 3000
90
S Menu 2-2 Compressor
COMP. IO POS: XXXXX
M. cutout C 1 XXX Digital input, motor overload cutout Compressor 1
(only shown when defined in system configuration: Menu 3-1)
Oil diff. pr. 1 XXX Digital input, low oil pressure cutout/high-pressure cutout Compressor 1
(only shown when defined in system configuration: Menu 3-1)
Man.sw. C 1 XXX Compressor manual switch ON-OFF-AUTO
Comp. C 1 XXX Digital output Capacity Stage 1
... Only the actual number of compressors is shown
M. cutout C 12 XXX Digital input, motor overload cutout Compressor 12
(only shown when defined in system configuration: Menu 3-1)
Oil diff. pr. 12 XXX Digital input, low oil pressure cutout/high-pressure cutout Compressor 12
(only shown when defined in system configuration: Menu 3-1)
Man.sw. C 12 XXX Compressor manual switch ON-OFF-AUTO
Comp. C 12 XXX Only the actual number of compressors is shown
VS 3000 basic module: Cylinder head temperature 1 - max. 4
With 1st SIOX extension module: Cylinder head temperature 1 - max. 8
With 2nd SIOX extension module: Cylinder head temperature 1 - max. 12
S Menu 2-3 Condenser fan
COND FAN POS: XXXXX
M. cutout F 1 XXX Digital input, motor overload cutout Fan 1
Fan 1 XXX Digital output Fan 1
Fast speed 1 XXX Toggle from star to delta mode for Fan Motor 1 (only shown when star-delta toggle acti-va-
ted 3-2-2-1-b, actuation type SSFF or SSSF selected)
... Only the actual number of fans is shown
M. cutout F 12 XXX Digital input, motor overload cutout Fan 12
Fan 12 XXX Digital output Fan 12
Fast speed 6/11* XXX Toggle from star to delta mode for Fan Motor 12 (only shown when star-delta toggle activa-
ted 3-2-2-1-b, actuation type SSFF or SSSF selected) *
VS 3000 basic module: Fan 1 - max. 4
With 1st SIOX extension module: Fan 1 - max. 8
With 2nd SIOX extension module: Fan 1 - max. 12
* High speed available to Stage 6 only in SSFF mode and to S t age 11 in SSSF mode.
