Econ sens3 - Multiple I;O; DC supply voltage

Technical Data 83
Manual econ sens3 Version 3.0
Multiple I/O
Open collector output
Switching voltage
max. 30 VDC
Switching current
max. 20 mA DC
Maximum switching frequency
10 Hz
Digital input
Minimum voltage
2 VDC
Maximum voltage
30 VDC
Minimum pulse length
20 ms
Input for potential-free contact
Minimum pulse length
20 ms
Analog voltage input
Switching voltage
max. 30 VDC
Connection capacity of the “multiple I/O” clamping point
Plug connector: pluggable MC 1.5/5-ST screw terminal
Rigid, stranded, or fine-wire conductor without ferrule [mm²]
0.14
1.5
Fine-wire with ferrule without plastic collar [mm²]
0.25
1.5
Fine-wire with ferrule with plastic collar [mm²]
0.25
0.5
Fine-wire with TWIN ferrule with plastic collar [mm²]
0.5
0.5
Min/max AWG conductor cross sections
28
16
Stripping length
7mm
Min/max tightening torque [Nm]
0.22
0.25
DC supply voltage
Protection of the supply voltage (fuse)
2A
Nominal range
12 to 28V
Operating range
+-10% of nominal range
Power consumption
max. 6W
