Vital Signs Monitor Service Manual Installation
- 8 -
Chapter 3 Installation
WARNING
Only qualified service engineers shall install this equipment.
3.1 Environment Requirements
Temperature
Working
0 C ~ +40 C (32 ℉~104 ℉)
With TEMP: +10 C ~ +40 C (50 ℉~104 ℉)
Transport and storage
-20 C ~ +55 C (-4 ℉~131 ℉)
With TH module: -20 C ~ +50 C (-4 ℉~122 ℉)
Humidity
Working
15% RH ~ 95% RH (non-condensing)
Transport and storage
15% RH ~ 95% RH (non-condensing)
Altitude
Working
86 kPa ~ 106 kPa
Transport and storage
70 kPa ~ 106 kPa
NOTE:
1 If the monitor is installed in a cabinet, allow at least 2 inches (5 cm) clearance around
the monitor for proper air circulation; allow adequate accessibility for servicing, and
adequate room for visualization and operation.
2 Ensure the monitor is not subjected to any source of strong electromagnetic
interference, such as CT, radio transmitters, mobile phones base stations, etc.
3 Do not install the monitor in the presence of flammable anesthetics.
4 Keep the environment clean and keep the device away from corrosive medicine.
Prevent the device from vibration, high temperature, humidity and exposure to the
sun.
3.2 Electrical Requirements
Operating Voltage
100 V-240 V ~
Operating Frequency
50 Hz/60 Hz
Input Current
0.7 A-0.35 A
Fuse
T2.5AH, 250VAC
