EDAN iM3 Service Manual

Vital Signs Monitor Service Manual Test and Maintenance
- 21 -
Leakage Current
Applied
Part
Normal
Condition
Single Fault
Condition
Earth Leakage Current
<0.5 mA
<1 mA
Enclosure Leakage Current
<0.1 mA
<0.5 mA
Patient Leakage Current
CF
AC: <0.01 mA
DC: <0.01 mA
AC: <0.05 mA
DC: <0.05 mA
BF
AC: <0.1 mA
DC: <0.01 mA
AC: <0.5 mA
DC: <0.05 mA
Patient Leakage Current (Mains on
Applied Parts)
CF
<0.05 mA
BF
<5 mA
Patient Auxiliary Current
CF
AC: <0.01 mA
DC: <0.01 mA
AC: <0.05 mA
DC: <0.05 mA
BF
AC: <0.1 mA
DC: <0.01 mA
AC: <0.5 mA
DC: <0.05 mA
4.3.5 Patient Leakage Current- Single Fault Condition (S.F.C) Mains on
Applied Part
NOTE:
The following test is based on test with the Fluke 601 pro series safety analyzer. This
device allows applying a 110% mains voltage between the applied part and the device PE.
When testing with other device, you may need to apply the 110% mains voltage manually.
