Vital Signs Monitor Service Manual Troubleshooting
- 32 -
7.4 Recorder Failures
Phenomenon
Possible Cause
Solution
Press Record but no
paper is out.
No paper in the drawer.
Load paper and close the drawer.
The drawer is open.
Close the drawer.
Paper is jammed.
Open the drawer and remove the
paper. Reload paper and close the
drawer.
Recording control board failure.
Replace the recording control
board.
Recorder connection failure.
Check all the connections.
Gear box/ gear failure.
Replace the gear box or the gear.
Main control board failure.
Replace the main control board.
The correct printer module
category was not selected.
Set in Factory Maintain. Turn on
the printer mode. If the printer is
Unicode, select U, otherwise E.
Alarm is displayed
onscreen as “out of
paper”, but there is
still paper in the
drawer.
The detector of recording paper
is contaminated.
Clean the detector of recording
paper.
Detector of recording paper
failure.
Replace the detector of recording
paper.
The drawer is not fastened up.
Fasten up the drawer.
Trace on the
recording paper is
blurred or tilts; or it
is blank on the paper.
Inexact loading of the recording
paper.
Load the recording paper exactly.
The two screw nuts on the print
head are not adjusted to balance.
Adjust the screw nuts.
Recording head failure.
Replace the recording head.
