Vital Signs Monitor Service Manual Replaceable Parts
- 62 -
Chapter 9 Replaceable Parts
WARNING
Only connect the replaceable parts supplied by EDAN to the monitor.
Parts
Part Number
iM3 main board PCBA (debugged)
02.03.452351
iM series power module main board PCBA (debugged)
02.03.220400
SunTech Advantage HT TEMP module
01.48.000636
Wi-Fi interface board PCBA (debugged)
02.03.451683
iM3 battery and Bluetooth interface board PCBA (not
debugged)
02.02.220524
iM3 battery interface board (without Bluetooth) PCBA (not
debugged)
02.02.220587
X2 air valve components
01.58.472153
Lithium-Manganese Button Cell
01.21.064095
Air pump
01.58.472151
iM3 parameter board (EDAN SpO
2
) PCBA (debugged)
02.03.220513
iM3 parameter board (NELLCOR SpO
2
) PCBA (debugged)
02.03.220516
iM3 sensor board of main unit (EDAN SpO
2
) PCBA (not
debugged)
02.02.220519
iM3 sensor board of main unit (NELLCOR SpO
2
) PCBA (not
debugged)
02.02.220521
SpO
2
module
02.08.208106
Speaker
01.14.038040
8-inch LCD screen
01.16.045272
Micro SD card
01.17.052452
iM3 alarm indicator board PCBA
02.02.220577
iM3 Rotary knob PCBA
02.02.452353
iM3 key board
02.48.027329
iM3 Pressure screen components (EDAN, touch screen)
02.01.213973
iM3 Pressure screen components (EDAN, Acrylic)
02.01.213974
iM3 Pressure screen components (Neutral, touch screen)
02.01.213975
iM3 Pressure screen components (Neutral, Acrylic)
02.01.213976
QR code scanning module
01.48.099051
iM3 network and USB interface board PCBA (not debugged)
02.02.220523
M3 Infrared Ear TEMP communication isolation board PCBA
02.03.451308
