6.2 Interface
Figure 6-2
No
Interface Description
1
Portable handle/Accessory collecting
2
Battery compartment latch
3
Equipotential grounding terminal.
4
AC power input
5
Power cable safety latch.
6
OTG interface/nurse call port
7
USB interface
8
Network interface
9
Battery
1
2
3
4
5
9
6
7
8
