TROUBLESHOOTING 107
The drive required is:
•Present
• Correctly installed
• Not visibly damaged
• Jumpered as the master (secondary) according
to label
• Activity LED lights on power up
DVD drive SATA cable is:
• Firmly connected to motherboard SATA 0
• Not visibly damaged
DVD drive, page 84
Each cable required is:
•Present
• The correct type
• Installed in the correct connector
• Well-seated
• Not visibly damaged (including connectors)
UIB cable, page 50
Hard disk drive data cable, page 76
Printer interface cable, page 48
DVD drive power and data combination cable, page 84
Power cable(s), page 73
If included in the system, the required mouse, monitor, and keyboard
are present and appear undamaged. The mouse and keyboard are
connected to the correct ports on the E-42B connector panel.
The cables required are:
•Present
• Installed in the correct connector
• Well-seated
• Not visibly damaged (including connectors)
• Mouse (if applicable)
• Monitor (if applicable)
• Keyboard (if applicable)
• Monitor power cord (not pictured)
TABLE 1: Verifying the system
