USING THE E-42B 24
USING THE E-42B
Three main user interfaces are available for the E-42B:
• The control panel on the front of the E-42B
• The copier/printer touch panel (see page 27)
• The Fiery Advanced Controller Interface (FACI), which includes a monitor, keyboard, and
mouse.
Using the E-42B control panel
The control panel on the front of the E-42B allows you to do the following:
• Eject CDs and DVDs (a hardware eject button is also provided below the disc slot)
• Replace the motherboard (when the motherboard replacement dongle is inserted into a
USB port)
• View the IP address of the E-42B
• Shut down, restart, or reboot the E-42B (see page 32).
NOTE: You can also shut down and restart the E-42B through the copier/printer touch panel
(see page 27).
• Interact with the E-42B during software installation (see page 87)
• Run certain diagnostics
.
FIGURE 3: E-42B control panel
Display window
Line selection buttons
Up button
First
Fourth
Menu button
Down button
Activity light
