REPLACING PARTS 43
Opening the E-42B
To service internal components, open the E-42B as described in the following procedure.
• The E-42 weighs approximately 20Kg. Be careful when moving the device.
• Never lift the E-42B by grasping the top panel. The top panel does not support the weight of
the system.
AVERTISSEMENT: Ne jamais soulever le serveur d'impression par sa partie supérieure : celle-ci ne peut pas supporter le
poids du système.
AVVERTENZA: Il server di stampa non deve essere mai sollevato afferrandolo dal pannello superiore, in quanto
quest'ultimo non può sostenere il peso dell'intero sistema.
WARNUNG: Heben Sie den Druckserver nicht an der oberen Gehäuseabdeckung an. Die obere Gehäuseabdeckung ist
nicht dafür ausgelegt, das Gesamtgewicht des Systems zu tragen.
ADVERTENCIA: No levante nunca el servidor de impresión agarrándolo por el panel superior. El panel superior no
soporta el peso del sistema.
AVISO: Nunca erga o servidor de impressão pelo painel superior. O painel superior não suporta o peso do sistema.
WAARSCHUWING: Til de afdrukserver nooit op door het bovenpaneel vast te nemen. Het bovenpaneel kan het gewicht
van het systeem niet dragen.
TO OPEN THE E-42B
1 Shut down the E-42B (see page 40).
2 Remove all cables from the back of the E-42B.
3 Remove the E-42B from the furniture (see page 44).
4 Remove all panels necessary to access the component that you need to service.
For guidelines on which panels to remove, see the service procedure for the component that
you want to access.
NOTE: When removing multiple panels from the E-42B, use the following order:
• Left panel (see page 44)
• Right panel (see page 44)
• Front panel (see page 45)
• Top panel (see page 46)
NOTE: When replacing panels, reverse the order.
5 Place the E-42B on a flat surface. Attach an ESD wrist strap before handling internal parts
(see page 13).
6 Carefully position the E-42B so that it is resting on its side and the internal components are
facing up.
Place removed components on a grounded, antistatic surface.
