INSTALLING HARDWARE 19
Connecting the E-42B
You are now ready to make the following connections:
• Monitor, keyboard, and mouse
• Power cable connection
• Network cable connection
• Ethernet crossover cable connection
For more information on connecting cables, see page 35.
Connecting the monitor, keyboard, mouse, and power
Before using the E-42B, connect the monitor, keyboard, mouse, and power to the E-42B if
applicable.
TO CONNECT THE MONITOR, KEYBOARD, MOUSE, AND POWER
NOTE: For detailed information about the monitor, keyboard, and mouse, see the
documentation that accompanies those products.
1 Make sure that the E-42B is installed in the furniture and that the monitor is securely
attached to the top of the E-42B.
For more information, see the assembly instructions that accompany the furniture.
2 Place the keyboard in the keyboard tray on the underside of the furniture table top. Place the
mouse on the table top.
3 Connect the keyboard and mouse cables to the USB ports on the E-42B connector panel.
4 If the monitor DVI cable is not already attached to the monitor, attach it according to the
instructions provided with the monitor. Connect the other end of the cable to the monitor
DVI port on the back of the E-42B.
Depending on your E-42B, the configuration of the DVI port may vary.
NOTE: The VGA cable provided with the monitor is not used.
5 Connect the monitor power cable to the back of the monitor (some monitors may already
have this cable attached). Connect the other end of the cable to a wall outlet.
Be sure to use the appropriate power cable for your regional outlet type.
6 Connect the recessed end of the E-42B power cable to the power connector to the E-42B
connector panel. Connect the other end of the cable to a wall outlet.
