REPLACING PARTS 85
TO REPLACE THE DVD DRIVE
1 Install the DVD drive in the switch bank assembly.
2 Install the switch bank assembly in the component sled, and then install the component sled
in the chassis (see page 82).
3 Attach the power and data combination cable to the back of the DVD drive.
4 If you installed a new DVD drive, make sure to reset the time and date in Setup (see
Configure Help for more information).
5 Reassemble the E-42B and verify its functionality (see page 85).
Restoring and verifying functionality after service
Before you leave the customer site, make sure that you complete the following steps. If you
cannot complete a step, determine the reason and correct the problem before continuing.
For more information, see Troubleshooting on page 102.
TO REASSEMBLE THE E-42B AND VERIFY FUNCTIONALITY
1 Reseat all boards, cables, connectors, and other parts loosened or removed during service.
When routing cables inside the E-42B, make sure that:
• Covers are securely installed after routing cables
• Cable routing does not interfere with the operation of internal components nor interfere
with removing or replacing components
• Cables are not tangled nor looped around internal circuit boards or components
(such as capacitors and resistors)
• Cables do not lie on or against any internal heating element
• Cables do not interfere with opening or closing E-42B panels
• Cable slack is secured with a tie-wrap
2 Restore the E-42B to the upright position.
3 Replace any panels that you removed earlier, as described on page 43.
4 If you replaced the motherboard, make sure that the new motherboard solves the problem
that you are troubleshooting, and then transfer options to the new motherboard (see
page 63).
5 If the E-42B is to be mounted on the furniture with the monitor, see the reassembly
instructions on page 132.
6 Connect the power cable to the E-42B (see page 19).
7 Connect the E-42B to the copier/printer (see page 20).
