SERVICING THE E-42B WITH FURNITURE 135
6 Use the handle on the stability bracket to lift the rear of the E-42B. Slide the E-42B all the
way forward into the stand. Lock the E-42B into place with the two thumbscrews that you
removed earlier.
7 Connect the two monitor cables (power and video):
• Power to the back of the monitor and to the wall outlet
•
Video to the back of the monitor and to the back of the E-42B
Stability bracket (lock into
place with two thumbscrews)
Video cable
Power cable
