- AB620A5035 Instruction Manual
- 58 -
N.C. 0V
IN12 IN13 +24V (1)
N.C.
6
1
BI1179
B22 1 2 3 4 5 6
RJ11(6P4C)*)
(F-550)
(F-551)
IN12
Input 12, function programmable using
parameter 550
IN13
Input 13, function programmable using
parameter 551
Connecting the analogous actuator EB401
EB.. = Actuator
Code table for digital target value preset (grey code)
Pedal step 
-2
-1
0
½
1
2
3
4
5
6
7
8
9
10
11
12
Input A (B80/8)
L
L
H
H
H
L
L
H
H
L
L
H
H
L
L
H
Input B (B80/6)
L
H
H
L
L
L
H
H
H
H
L
L
L
L
H
H
Input C (B80/4)
H
H
H
H
L
L
L
L
L
L
L
L
H
H
H
H
Input D (B80/7)
H
H
H
H
H
H
H
H
L
L
L
L
L
L
L
L
