APPElUDlX A
ACCESSORIES
MODEL
590 FREQUENCY EXTElUSlON CABLE KIT
The kit, part number 2000025 contains:
1
- LO Cable (long) - 204021 7
1
- IF Cable (short) - 2040218
1
- Adaptor (SMA to TNC) - 2610063
0-4
- Remote Sensors (Options 91 thru 94)
REMOTE SENSOR OPTIONS
FREOUENCYRANGE 7
9 1
9 2
93
94
SPECIFICATIONS
PART NUMBER
2030022
2030029
2030030
2030031
BAND 4
Used with
548A/06 Counter and 590 Frequency Extension kit
OPTIONS
SELECT BAND
Waveguide Band
Range
Sensitivity (typ)
Waveguide Size
Waveguide Flange
Max. Input
(typ)
Damage Level
9 1
4 1
Ka
26.5-40
GHz
-25 dBm (-20 dBm min.)
WR-28
UG-599lU
+5 dBm
+10 dBm
94
44
W
90-1 10 GHz
-25 dBm
WR-10
UG-387/U
+5 dBm
+10 dBm
92
42
U
40-60
GHz
-25 dBm
WR-19
UG-383/U
+5 dBm
+10 dBm
93
43
E
60-90 GHz
-25 dBm
WR-12
UG-387/U
+5 dBm
+10 dBm
