35
Chapter 2 Conguring from the monitor screen
Saving system log data
1. Connect a USB storage device to the USB downstream port on the back of the monitor.
USB downstream port
2
3
4
Displays the data
storage status.
5
2. Select “System Log”.
3. Select the date (year / month / day) of the log data to display.
4. Select “Run” for “Save to USB Storage”.
Data saving starts and a “Saving” message is displayed in the display area on the right side of the screen.
When the saving complete screen is displayed, select “OK”.
5. Select “Run” for “Remove USB Storage”.
When the removing complete screen is displayed, select “OK”.
6. Remove the USB storage device.
Attention
• The following USB storage devices can be used with this product (This does not guarantee operation of the
USB storage devices given below).
- USB 2.0 standard ash drives
- Supported format: FAT32
• Do not connect multiple USB storage devices simultaneously.
To Next Page
