Chapter 2 Conguring from the monitor screen
Troubleshooting
Use this function when this product does not operate normally, such as when a connection cannot be
established with a network camera or a communication error occurs. The network status can be
checked using communication commands and past error contents can be checked by displaying the
system log. In addition, system log data can be saved to a USB storage device.
Checking network connection status
1
2
3
Displays the
connection check
results.
1. Select “Connection Conrmation”.
2. Select the network camera to check the network connection of for “Camera Name”.
3. Select “Run” for “ping” or “traceroute”.
Results are displayed in the area on the right side of the screen.
Displaying the system log
1
2
3
Displays the log.
1. Select “System Log”.
2. Select the date (year / month / day) to display the log data of.
3. Select “Run” for “Display”.
The log data is displayed in the area on the right side of the screen.
