Chapter 3 Conguring from a Web Browser
3. Select “Manual Registration”.
A “Camera Information Settings” dialog box appears. When a registered camera is selected, a dialog box
describing the applicable camera information appears.
Item Detail Setting range
Camera Name Enter the camera name. When “Obtain Camera
Name” is selected, the camera name is
automatically obtained from the network camera.
• Panasonic network camera: Camera Name
• AXIS network camera: Camera Name
• Network camera with its “Protocol” set to
“ONVIF”: Camera model number, manufacturer
name, etc.
Alphanumerics, kana, and
kanji (24 characters max.)
IP Address Enter the network camera IP address. 0.0.0.0 to 255.255.255.255
Port Enter the network camera port number. 1 to 65535
*1
Protocol Select the protocol for controlling the camera. Panasonic / AXIS / ONVIF /
DirectUri
Username
*2
Enter the username to use when accessing
network cameras.
Alphanumeric, symbols
(up to 32 characters)
Password
*2
Enter the password to use when accessing
network cameras.
Alphanumeric, symbols
(up to 32 characters)
Stream
*3
Select a stream for delivering camera images.
Select a stream supported by the connected
network camera.
CH1 to CH4
Channel
*3
Select the channel of the analog encoder. If the
network camera does not support the channel
function, set to “1”.
CH1 to CH4
RS485 PTZ Control
*3
Controls the brightness, automatic focus
adjustment, pan, tilt and zoom for devices that are
connected to the network camera via a RS485
cable.
On / Off
Video Stream
*4
Select the display mode for screens that
display the network camera images. When
“Obtain Stream” is selected, the display mode is
automatically selected from the network camera.
According to the camera
specication
