Eizo DuraVision FDF4627W-IP

52
Chapter 3 Conguring from a Web Browser
Stream Prole
*4
Select the prole that the network camera has.
When “Obtain Prole” is selected, the prole is
automatically selected from the network camera.
According to the camera
specication
Media Prole
*5
Select the ONVIF image prole. When “Obtain
Prole” is selected, the prole is automatically
selected from the network camera.
EIZO_Prole / camera prole
Transmission Mode
*6
Select the transmission mode for camera images. Unicast / Multicast
URI
*7
Set the URI that starts with rtsp:// or rtp://. Alphanumeric
(up to 255 characters)
Comm. Method Select the Comm. Method for camera images. RTP over UDP
*8
/
RTP over RTSP
*1 If the “Protocol” is set to “DirectUri” and if the “URI” starts with rtp://, 1824 to 65534.
*2 Enter the username with administrator rights and the password. Congure as necessary if the “Protocol”
is set to “DirectUri”.
*3 Compatible only if the “Protocol” is set to “Panasonic”.
*4 Compatible only if the “Protocol” is set to “AXIS”.
*5 Compatible only if the “Protocol” is set to “ONVIF”.
*6 Compatible only if the “Protocol” is set to “AXIS” and “ONVIF”.
*7 Compatible only if the “Protocol” is set to “DirectUri”.
*8 Possible to set only “RTP over UDP” in the following cases.
• In the case where “Protocol” is set to “Panasonic”.
• In the case where “Protocol” is set to AXIS” and “Transmission Mode” is set to “Multicast”.
• In the case where “Protocol” is set to “ONVIF” and “Transmission Mode” is set to “Multicast”.
• In the case where “Protocol” is set to “DirectUri” and “URI” starts with rtp://
4. Set the changes, and select “OK”.
Returns to the camera registration information list screen in step 1.
5. Select “Apply”.
A setting conrmation dialog box appears.
6. Select “OK”.
Note
• The following message is displayed when the system fails to acquire the “Obtain Camera Name” and “Obtain
Prole” information. Obtain the information again.
