S86A
TRI (Trigger Output)
Description:
• Turns specified Programmable Trigger Output’s state off/on/toggle.
• Only works if Trigger is enabled in VIA!TOOLS or ELANTOOLS
Command:
&S86,TRI,tt,a<cr>
Query:
&S86,TRI,tt?<cr>
Reply:
&S86,TRI,tt,a<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
tt:
Trigger Output: 1-24
a:
0 = OFF
1 = ON
2 = TOG
Examples:
• &S86,TRI,13,0<cr> turns Trigger Output 13 off.
• &S86,TRI,03,2<cr> toggles Trigger Output 3 from on to off or off to on.
