elco TRIGON L PLUS - Page 59

59
Operation
Parameter listing
Menu Submenu Parameter Name Description Range Factory settings
24. 6 Congurable Inputs-Outputs
24. 6. 0 Multi In Temp 1
0 = None
1=Commonowsensor
2=DHWstoragetankbottom
3 = DHW circulation sensor
4 = DHW charging sensor
5=Bu󰀨erstoragetanktop
6=Bu󰀨erstoragetankbottom
7 = Flue gas temp sensor
0 - 7 1
24. 6. 1 Multi In Temp 2
0 = None
1=Commonowsensor
2=DHWstoragetankbottom
3 = DHW circulation sensor
4 = DHW charging sensor
5=Bu󰀨erstoragetanktop
6=Bu󰀨erstoragetankbottom
7 = Flue gas temp sensor
0 - 7 0
24. 6. 2 Multi In Temp 3
0 = None
1=Commonowsensor
2=DHWstoragetankbottom
3 = DHW circulation sensor
4 = DHW charging sensor
5=Bu󰀨erstoragetanktop
6=Bu󰀨erstoragetankbottom
7 = Flue gas temp sensor
0 - 7 0
24. 6. 3 Multi In Freq
0 = None
1 = Flowmeter
2 = Flow switch
0 - 2 0
24. 6. 4 Multi In AD 1
0 = None
1 = Room thermostat HC1
2 = Room thermostat HC2
3 = Room thermostat HC3
4 = 0-10V input request
5 = External operating mode changeover HCs+DHW
6 = Heat generation lock
7 = Timer CH
8 = Gas Pressure Switch
0 - 8 0
