elco TRIGON L PLUS - Page 60

60
Operation
Parameter listing
24. 6. 5 Multi In AD 2
0 = None
1 = Room thermostat HC1
2 = Room thermostat HC2
3 = Room thermostat HC3
4 = 0-10V input request
5 = External operating mode changeover HCs+DHW
6 = Heat generation lock
7=Fluegasdamperfeedback
8 = Pressure Switch
0 - 8 0
24. 6. 6 Multi In AD 3
0 = None
1 = Room thermostat HC1
2 = Room thermostat HC2
3 = Room thermostat HC3
4 = 0-10V input request
5 = External operating mode changeover HCs+DHW
6 = Heat generation lock
7=Fluegasdamperfeedback
8 = Pressure Switch
0 - 8 0
24. 6. 7 Multi In AD 4
0 = None
1 = Room thermostat HC1
2 = Room thermostat HC2
3 = Room thermostat HC3
4 = 0-10V input request
5 = External operating mode changeover HCs+DHW
6 = Heat generation lock
7=Fluegasdamperfeedback
8 = Pressure Switch
0 - 8 0
24. 7 Congurable Inputs-Outputs 2
24. 7. 0 Multi Out HV
0 = None
1 = System pump
2 = HC1 Pump
3 = Circulating pump
4 = DHW intermediate circuit pump
5=BUFllingpump
6 = Storage tank transfer pump
7=Heatgenshuto󰀨valve
8 = Heat request
0 - 8 1
Menu Submenu Parameter Name Description Range Factory settings
