Parameter listing
Menu Submenu Parameter Name Description Range Factory settings
24. 7. 1 Free Contact 1
0 = None
1 = System pump
2 = HC1 Pump
3 = Circulating pump
4 = DHW intermediate circuit pump
5=BUFllingpump
6 = Storage tank transfer pump
7=Heatgenshuto󰀨valve
8 = Heat request
9 = Alarm output
10 = Flue Gas Dumper
11 = Lpg/Room Supply Fan
0 - 11 0
24. 7. 2 Free Contact 2
0 = None
1=Heatgenshuto󰀨valve
2 = Heat request
3 = Alarm output
4 = Lpg/Room Supply Fan
0 - 4 0
24. 7. 3 Free Contact 3
0 = None
1=Heatgenshuto󰀨valve
2 = Heat request
3 = Alarm output
4 = Lpg/Room Supply Fan
0 - 4 0
24. 7. 4 Multi Out PWM 1
0 = None
1 = System pump modulator
2 = DHW Pump modulator
3 = Circulating pump modulator
4=BUFllingpumpmodulator
5=boilerpowerfeedback
0 - 5 1
24. 7. 5 Multi Out PWM 2
0 = None
1 = System pump modulator
2 = DHW Pump modulator
3 = Circulating pump modulator
4=BUFllingpumpmodulator
5=boilerpowerfeedback
0 - 5 0
24. 8 Boiler manual settings
24. 8. 0 Manual mode activation
OFF
ON
0 - 1 0
24. 8. 1 Boiler pump control
OFF
ON
0 - 1 0
