Connection Information
Please refer to the electrical schematics above and to the electrical connection section 4.7.
For more details please refer to the Termination Board Instruction Manual.
Model HiD 2822:
Screw terminal number Used for
11 Safe area 1 SPST output, Ch. 1
14 Safe area 1 SPST output, Ch. 1
17 Safe area 2 SPST output, Ch. 1
18 Safe area 2 SPST output, Ch. 1
12 Safe area 1 SPST output, Ch. 2
15 Safe area 1 SPST output, Ch. 2
13 Safe area 2 SPST output, Ch. 2
16 Safe area 2 SPST output, Ch. 2
19 Safe area Shield
1 Hazardous area input +, Ch. 1
4 Hazardous area input -, Ch. 1
2 Hazardous area input +, Ch. 2
5 Hazardous area input -, Ch. 2
9 Hazardous area Shield
3, 6, 7, 8 not used
Model HiD 2824:
Screw terminal number Used for
11 Safe area SPST output, Ch. 1
14 Safe area SPST output, Ch. 1
12 Safe area SPST output, Ch. 2
15 Safe area SPST output, Ch. 2
13 Safe area SPST output, Ch. 3
16 Safe area SPST output, Ch. 3
17 Safe area SPST output, Ch. 4
18 Safe area SPST output, Ch. 4
19 Safe area Shield
1 Hazardous area input +, Ch. 1
4 Hazardous area input -, Ch. 1
2 Hazardous area input +, Ch. 2
5 Hazardous area input -, Ch. 2
3 Hazardous area input +, Ch. 3
6 Hazardous area input -, Ch. 3
7 Hazardous area input +, Ch. 4
8 Hazardous area input -, Ch. 4
9 Hazardous area Shield
