Electrolux T4130 - Program Unit Menu Structure; Menu Tree Overview

13
Menu tree
The machine software is constructed with menus that are
structured according to the menu tree below. The menus
become available when the machine is in service mode,
see section "Engaging service mode".
Program unit
SERVICE
PARAMETER PROGR.
STATISTICS
CONFIG. 1
CONFIG. 2
COIN VALUE
QUICK START BUTTONS
ADJUST DISPLAY
RESET
MAIN MENU
USER INTERFACE
SHOW COUNTER
LANGUAGE
SPECIAL CONTROL
I/O ADDRESS
CONFIG 1
ACTIVATE OUTPUTS
SHOW INPUTS
ARTICLE NUMBER
SHOW COM. PORTS
STATUS I/O BOARD
DISPLAY TEST
SERVICE
CONFIG PCB
TEMPERATURE
ROTATION
MAXIMUM
RESET COUNTERS
ELS NETWORK
CONFIG 2
See programming manual
See programming manual
See programming manual
See programming manual
See programming manual
HEAT
DIRECTION
EXT. SIGNAL
FAN
DRUM
DOOR CLOSED
VACUUM
EXTERNAL INPUT
PRICE REDUCTION
FILTER CLOSED
OVERHEAT
GAS INPUT
FAN OVERHEAT
DRUM OVERHEAT
FREE DRY
COIN 1
COIN 2
QUICK START 1
QUICK START 2
ANALOG
SOFTWARE VERSION
PARAMETER VERSION
BUTTON CLICK
STANDBY VALUE
STANDBY VALUE BLINKS
FINAL BLINKS
TIMEOUT DISPLAY SEC
TIMEOUT END BUZZ SEC.
SHOW TIME
SHOW TEMP
DEFAULT TEMP
SHOW COIN COUNTER
SHOW HOUR COUNTER
DEFAULT LANGUAGE
LANGUAGE TIMEOUT SEC.
SHOW °F
REVERSING ON/OFF
TYPE OF HEATING
PAYMENT SETTING
CONTROL PANEL
PROGRAMS
INLET TEMPERATURE
HYSTERESIS
AUTOSTOP
CLOCKWISE
PAUSE BETWEEN REV.
REVERSING
ANTICREASE
NUMBER OF PROGRAMS
TIME ON TIME P.
TIME ON AUTOMATIC P.
PENDLING TIME
RESET SERVICE HOURS
RESET TRIP RUN HOURS
MACHINE ADDRESS
BAUD RATE
TIME OUT
DRYER TYPE
CONFIG. 3
See programming manual
