Electrolux T4130 - Display Test Procedure; Performing Display Diagnostics

21
Program unit
17
6204
SERVICE
MENU 1-6
DISPLAY TEST
EXIT
DISPLAY TEST
Select the row DISPLAY TEST and press the
knob.
The display shows a checked grid for checking
that all segments in the display are intact. By
turning the knob two different grids are shown.
Press the knob to return to the previous menu.
Fig.
17
18
6204
Fig.
18
