9
Connector numbers
In the error analyses in the section "Troubleshooting" later in this manual connections
P1-P23 are mentioned.
The P-numbers are printed on the print board.
The usage of the connections appears from the wiring diagrams supplied with the dryer.
The positionings of P1-P23 are shown on the following page.
High voltage on the printed circuit board
Do not touch the printed circuit board.
The shaded areas indicate high voltage.
Description
Warning!
The shaded areas indicate high voltage
See view 2
next page
1
See view 1
next page
