Electrolux T4130 - Activating Machine Outputs; Output Function Selection

17
9
6204
8
6204
SERVICE
MENU 1-1
ACTIVATE OUTPUTS
SHOW INPUTS
ARTICLE NUMBER
SHOW COM. PORTS
STATUS I/O BOARD
ACTIVATE OUTPUTS
MENU 1-1-1
HEATSHOW INPUTS
DIRECTION
EXT SIGNAL
FAN
DRUM
ACTIVATE OUTPUTS
Select the row ACTIVATE OUTPUTS and press
the knob.
The display now shows the functions (outputs)
which can be activated:
• HEAT
• DIRECTION
• EXT SIGNAL
• FAN
• DRUM
Select function and press the knob.
Fig.
9
Fig.
8
Program unit
