7 Devices
iConnect Installation Manual
46
Common Zones: zones assigned to both partitions P1 and P2 (Arm Set 123 or 23). An alarm should be
generated from common zones only if the system has been full armed or both partitions 1 and 2 have
been armed.
Note: When defining a zone as a common zone, the zone type definition must be Normal, Entry/Exit, or
Follower.
Note: The system can be armed in a specific arm mode or partition, only if there is at least one zone assigned
to it.
A zone assigned to both partitions (Arm Set 123 or 23) is a common zone – see p. 24, Common zones.
To program the Arm Set option:
1. From the Programming menu, select Devices, Zones [911].
2. Select the zone you want to program.
3. From the zone’s sub-menu, select Arm Set [#03]; the zone’s current Arm Set setting is displayed.
Unpartitioned systems Partitioned systems
Arm Set Description Arm Set Description
1 (F) The zone is included in Full arming. 1 (F) The zone is included in Full arming.
2 (P) The zone is included in Part arming. 2 (P1) The zone is included in Partition 1.
3 (PE) The zone is included in Perimeter
arming.
3 (P2) The zone is included in Partition 2.
Table 7-1: Arm Set Options
4. Use the keys 1, 2 and 3 to toggle the current setting.
Note: It is not necessary to program this option for Panic, Medical, Emergency, Fire, 24Hr, Gas, Flood and
Environmental zones.
7.3.3. Descriptor
For information on device descriptor editing, see p. 43, 7.1 Device Descriptors
7.3.4. Bell (Siren)
Each zone can be programmed to activate the siren when triggered or to generate a silent alarm where only a message
is sent to the central station.
To program the Bell option:
1. From the Programming menu, select Devices, Zones [911].
2. Select the zone you want to program.
3. From the zone’s sub-menu, select Bell [#05]; the zone’s current Bell setting is displayed.
4. Select either Enabled or Disabled.
Note: Fire zones always activate the siren regardless of what is programmed for this option.
If the bell is disabled for Panic zones, this also disables all forms of alarm indication from the on-board
keypad in the event of a Panic alarm.
If the Bell option is enabled for Environmental or Flood zones, the system sounds trouble tones from
the keypad.
7.3.5. Chime
When Chime is enabled, triggering the zone when the system is disarmed causes the internal siren to chime.
To program the Chime option:
1. From the Programming menu, select Devices, Zones [911].
2. Select the zone you want to program.
3. From the zone’s sub-menu, select Chime [#06]; the zone’s current Chime setting is displayed.
4. Select either Enabled or Disabled.
