Winding the bobbin
1 Pull out the flywheel to disengage the clutch.
1 flywheel
2 Draw the thread from the spool. Guide the thread
around the bobbin winder thread guide.
2
Bobbin
winder
thread
guide
3 Thread through the hole in the bobbin from the inside
to the outside.
Put the bobbin on the bobbin winder spindle with the
free end of the thread coming out at the top.
3 Bobbin winder spindle
4 Push the bobbin to the right.
NOTE:
Do not move the bobbin winder spindle while the
machine is running.
5 With the free end of the thread held in your hand,
depress the foot control. Stop the machine when the
bobbin has been wound a few layers, and cut the
thread
close
to
the
bobbin.
6 Depress the foot control again. When the bobbin is
fully wound, it will stop automatically.
Return the bobbin winder to its original position by
moving the spindle to the left, and cut the thread as
To Next Page
