30
z
Threading the Machine
To set the needle thread:
Raise the thread take-up lever to the highest position b
turning the handwheel.
Raise the presser foot.
WARNING:
Turn OFF the power switch before threading the needle.
1 Draw the thread from the spool and pass it under the
thread guide. Then draw it down along the right
channel.
1 Thread guide
2 Right channel
2
Draw the thread up around
the
bottom of the thread
guide plate.
Pull the thread up along the left channel
3 Thread guide plate
4 Left channel
3 Firmly draw the thread from right to left over the
thread take-up lever and down into the take-up leve
eye.
5 Thread take-up lever
4 Draw the thread down along the left channel and slip
the thread behind the needle bar thread guide from
the left.
6 Needle bar thread guide
5 Pass the thread through the needle eye from the front
or use the needle threader (refer to the next page).
Elna 320-340 Sewing Machine Instruction Manual
