ND
MAINTENANCE
WARNING:
Turn the power switch off and unplug the machine before
cleaning.
NOTE:
Do not dismantle the machine in any way other than
what is explained in this section.
Clean the outside of the machine with a soft cloth and
mild soap.
Cleaning the Hook Race
and
Feed
Dogs
1 Remove the presser foot and needle. Remove screw
on the needle plate with the screwdriver.
Remove the needle plate and take out the bobbin.
1 Screw
2 Lift up the bobbin holder and remove it.
2 Bobbin case
3 Brush out dust and lint. Wipe the bobbin holder with a
soft, dry cloth.
4 Clean the feed dogs and hook race with the lint
brush.
3 Lint brush
4 Feed dogs
5 Wipe the hook race with a soft, dry cloth.
5 Hook race
NOTE:
You may also use a vacuum cleaner.
