• Loosen the four fastening screws of the upper part of the furnace and carefully remove
the furnace part.
• Remove the compressed air hoses from the two vertical pneumatic cylinders.
• Loosen the three screws which hold the electrode in place. Use the supplied Torx®
screwdriver for this purpose. Hold the electrode while performing this task.
NOTICE
Do not use a Torx® screwdriver with a ball head! The screws may be very tight and the
ball head could thereby tear off and damage the screw.
• Remove the electrode of the furnace from below.
• Remove the three screws with the sealing washers.
• Remove the flat seal.
