Document id: 1090055 Version 1.5
4.3 Step by step installation of wireless M-Bus meters using the display
This section describes a step by step guide how to install wireless M-Bus slaves in the product. The
installed wireless M-Bus slaves will be readable on any of the wired M-Bus slave ports on completion. This
section does not cover wireless M-Bus slaves which run in encrypted mode. Please see section 5 for a
complete description how to operate the CMeX50 display menu.
Up/down keys are used to scroll through the options.
Step by step guide:
1. After power up, following screen is shown:
Sl eep mode
Press any key
to l ogi n!
2. Press OK key to be able to enter the 4 digit password before the product can be accessed using the
key pad.
3. Enter the default password 0000 and press OK key:
Pl ease l ogi n
Enter password
0000
ESC=Cancel
OK=Logi n
4. Select menu choice 1. Installation by pressing OK key on selected item:
HOME
1. Instal l ati on
2. Meters
3. Setti ngs
4. Logout
5. Select Manufacturer (Mfr) or Meter (Dev). If left blank (---), all meters will be installed.
Proceed by pressing OK:
6. 1. Start, keep - Keep already installed meters and stay in installation mode for 60 min, (or chosen
time).
2. Start, clear all. – Clear all installed meters.
3. Start, cont. – Keep already installed meters and stay in installation mode (until it is manually
turned off).
Change installation choice with up/down keys, choose installation by pressing OK:
[1.1 Instal l fi l t ers]
Mfr: --- (al l )
Dev: --- (al l )
<+>=Cl ear fi l ters
ESC=Cancel
OK=Start i nstal l
[1.1 Instal l fi l t ers]
Mfr: --- (al l )
Dev: --- (al l )
<+>=Cl ear fi l ters
ESC=Cancel
OK=Start i nstal l
[1.2 Instal l ati on]
1. Start, keep
2. Start, cl ear al l
3. Start, cont.
--------------------
Mfr: --- (al l )
Dev: ---- (al l )
[1.2 Instal l ati on]
1. Start, keep
2. Start, cl ear al l
3. Start, cont.
--------------------
Mfr: --- (al l )
Dev: ---- (al l )
