8 Technical specifications
8.1 Characteristics
Type
Value
Unit
Comments
Mechanics
Casing material
Polyamide
-
White
Protection class
IP20
-
Dimensions (w x h x d)
105 x 90 x 65
mm
6 DIN modules
Weight
220
g
Mounting
Mounted on
DIN-rail (DIN
50022) 35
Mm
Electrical connections
Power supply
0.5-2.5
mm
2
Screw terminal
M-Bus master port
0.5-2.5
mm
2
Screw terminal
M-Bus slave port
0.6-0.8
Ø mm
Pin terminal solid wire
Antenna
SMA-f
-
RS232
RJ45 8/8
-
USB port
Mini USB type B
-
Electrical characteristics
Nominal voltage
100-240
VAC
+/- 10%
Frequency
50/60
Hz
Power consumption
<6
W
Installation category
CAT 2
-
Environmental specifications
Operating temperature
-25 to +55
°C
Reduced response time on LCD at
low temperature
Operating humidity max
5 to 90
%
Non-condensing
Operating altitude
0-2000
m
-
Pollution degree
Degree 2
-
Usage environment
Indoors
-
Can be extended with IP6x
enclosure for outdoor use
Storage temperature
-40 to +85
°C
User interface
LCD display
Graphic
monochrome
-
Display resolution
128 x 64
pixels
Keyboard
7 illuminated
buttons
-
M-Bus
