Acknowledge
6.3.29 Set meter lock flag
SND-UD with the following M-Bus record:
0x0DDIF ”variable length”
0xFCVIF ”plain text VIF” + extension bit for object action code
0x08length of plain text VIF (actual VIF is meter address)
0xnnmeter address ID lsByte
0xnnmeter address ID
0xnnmeter address ID
0xnnmeter address ID msByte
0xnnmeter address MANUFACTURER lsByte
0xnnmeter address MANUFACTURER msByte
0xnnmeter address VERSION
0xnnmeter address DEVICE TYPE
0x03/0x06object action code, 0x03 = set flag, 0x06 = clear flag
Individual flags are written by supplying the corresponding meter address.
The flags of all installed meters can be written (set or cleared) with a single command by setting all eight meter
address bytes to 0xFF.
Important note!
This command is useful only for changing lock flags of meters that are already installed in the meter list since a
meter's lock flag will always be cleared as default at the moment of installation.
6.3.30 Set configuration tag
The configuration tag can be used to indicate if changes have been made in the LCD menu after any
configuration has been made using the wired M-Bus interface.
6.3.30.1 Master to slave
Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x43 | 0x53 | 0x63 | 0x73
C-Field = SND_UD
5
0xnn
A-Field = Address of slave
6
0x51
CI-Field = Master to slave data send
7-13(14)
0x04FD0Bnnnnnnnn
OR
0x04FD0B00nnnnnnnn
Write configuration tag
nnnnnnnn = 32 bit unsigned tag
Valid range: 0x00 .. 0xFFFFFFFF
