Elvaco CMeX50 - Slave to Master; Set Wired M-Bus Mode; Master to Slave

CMeX50 Users Manual English
CMeX50 Users Manual English
page | 72 (89)
2017-10-13
Document id: 1090055 Version 1.5
6
0x51
CI-Field = Master to slave data send
7-14(15)
0x027C03656761nnnn
OR
0x02FC0365676100nnnn
Write wireless age limit
nnnn = 16 bit unsigned wireless age limit in
minutes
Valid rage: 0..9999 minutes
15(16)
0xnn
Checksum
16(17)
0x16
Stop character
6.3.20.2 Slave to master
Byte index
Data
Description
0
0xe5
Acknowledge
6.3.21 Set wired M-Bus mode
Set how wired M-Bus interface will transport information to requesting M-Bus master; Auto or in
Container mode. The Auto mode will try to transport the data to requesting M-Bus master as unmanaged
data received from the wireless M-Bus slave. The Container mode will encapsulate the complete wireless
M-Bus telegram in a container. The Container mode can be useful if key handling (decryption of
telegrams), should be handled centralized and not within the CMeX50.
See section 6.1.4 for more information about Auto and Container.
6.3.21.1 Master to slave
Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x43 | 0x53 | 0x63 | 0x73
C-Field = SND_UD
5
0xnn
A-Field = Address of slave
6
0x51
CI-Field = Master to slave data send
7-13(14)
0x017C036f6d74nn
OR
0x01FC036f6d74nn
Write wired M-Bus mode
nn = 8 bit unsigned wired M-Bus mode
Valid values:
0 = Auto
1 = Container
14(15)
0xnn
Checksum
15(16)
0x16
Stop character
6.3.21.2 Slave to master
Byte index
Data
Description
