Elvaco CMeX50 - Slave to Master; Delete Meter; Master to Slave

CMeX50 Users Manual English
CMeX50 Users Manual English
page | 76 (89)
2017-10-13
Document id: 1090055 Version 1.5
7-14(15)
0x0AFD16nnnn
OR
0x0AFD1600nnnn
Write LCD menu password
nnnn = 4 digit packed BCD password
15(16)
0xnn
Checksum
16(17)
0x16
Stop character
6.3.26.2 Slave to master
Byte index
Data
Description
0
0xe5
Acknowledge
6.3.27 Delete meter
Delete one or all installed meters from the product.
6.3.27.1 Master to slave
Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x43 | 0x53 | 0x63 | 0x73
C-Field = SND_UD
5
0xnn
A-Field = Address of slave
6
0x51
CI-Field = Master to slave data send
7-15(16)
0x0DFC08[ADDR]09
Delete one or all meters from the product.
[ADDR] = 8 byte wireless M-Bus address
Valid values:
0xFFFFFFFFFFFFFFFF = Delete all
OR
The corresponding 8-byte wireless M-Bus address
of the meter to delete:
ID
4 bytes
Man
2 bytes
Gen
1 byte
Dev
1 byte
16(17)
0xnn
Checksum
17(18)
0x16
Stop character
6.3.27.2 Slave to master
Byte index
Data
Description
