Elvaco CMeX50 - Slave to Master; Set Baud Rate; Master to Slave

CMeX50 Users Manual English
CMeX50 Users Manual English
page | 64 (89)
2017-10-13
Document id: 1090055 Version 1.5
7-13 (14)
0x01 0x7C 0x03 0x66 0x63
0x69 0xnn
OR
0x01 0xFC 0x03 0x66 0x63
0x69 0x00 0x01
0xnn = action upon receiving telegrams with CI =
0x79 or 0x69:
0x00 = Ignore the telegram.
0x01 = Place the telegram in a data container.
(0x66 0x63 0x69 = 'icf' backwards)
14 (15)
0xnn
Checksum
15 (16)
0x16
Stop character
6.3.9.2 Slave to master
Byte index
Data
Description
0
0xE5
Acknowledge
6.3.10 Set baud rate
Set baud rate of slave.
This command only changes the local baud rate if the CMeX50 product is addressed.
6.3.10.1 Master to slave
Byte index
Data
Description
0
0x68
Start character 1
1
0x03
L-Field 1
2
0x03
L-Field 2
3
0x68
Start character 2
4
0x43 | 0x53 | 0x63 | 0x73
C-Field = SND_UD
5
0xnn
A-Field = Address of slave
6
0xnn
CI-Field = Baud rate selection code:
0xb8 = 300 baud
0xb9 = 600 baud
0xbA = 1200 baud
0xbb = 2400 baud
0xbc = 4800 baud (note 1)
0xbd = 9600 baud (note 1)
0xbe = no change (note 2)
0xbf = no change (note 2)
Baud rates > 2400 baud do work but have not been
tested to comply with the timing specifications in
the M-Bus standard.
Baud rate codes 0xbe and 0xbf are ACKed with
0xe5 although they do not change the baud rate
(this is in accordance with the M-Bus specification).
