5.3 Meters menu page
In the meters menu (on the Home screen, choose 2. Meters), installed meters can be viewed and
removed. The menu layout is similar to the installation procedure page.
See Figure 5 for an overview of the informational parts of the meters menu page.
[2. Meters: Grp Man.]
Medi um Good Bad Tot
ALL 001 001 002
›LUG 000 001 001
ELV 001 000 001
‹: Medi um ›: Manuf
Number of meters
with good signal
strength.
Number of
meters with bad
signal strength.
Total number of
meters
(Good+Bad)
Selection cursor
Figure 5 Meters menu page overview
[2. Meters: Grp Man.]
Medi um Good Bad Tot
ALL 001 001 002
›LUG 000 001 001
ELV 001 000 001
‹: Medi um ›: Manuf
[2. Meters: Grp Med.]
Medi um Good Bad Tot
ALL 001 001 002
›Heat 000 001 001
Room s 001 000 001
‹: Medi um ›: Manuf
Left/Right
[2. Meters: LUG]
Id Age Status
›01234567 001 Good
‹ Sort Edi t Del ete >
[2. Meters: Room s]
Id Age Status
›01234567 001 Good
‹ Sort Edi t Del ete ›
ENT ENT
›ID: 01234567
Man: LUG
Type: Heat
Versi on: 4
Mode: T1
RSSI: -100 dBm
Age: 1 mi nutes
Encr: None
ENT
Type: Heat
Versi on: 4
Mode: T1
RSSI: -100 dBm
Age: 1 mi nutes
Encr: None
Status: Unencrypted
›Wi red: Auto
Up/Down
[2. Meters: Room s]
Id Age Status
›01234567 001 Good
‹ Sort Edi t Del ete ›
Right/Left
Bottom menu.
Use Right/Left
key to select
option and ENT
to accept.
Selected meter
information. Use
Up/Down key
to scroll.
Figure 6 Meters menu navigation overview
