0x44
SND-NR
Send unsolicited/periodical application data from
meter without request from master unit (Send /No
Reply)
0x46
SND-IR
Manually initiated sending of telegram with
request for installation in master unit (Send
Installation Request)
0x08, 0x18,
0x28 or 0x38
RSP-UD
Sending of application data after a request from
the master (response of user data)
Table 7 Handled C-Fields
6.1.4.2 Handle CI-fields
6.1.4.2.1 Handled CI-fields for ”Extended Link Layer”
CI- Field
Designation
Description
0x8C
Type I with CC- and ACC-field
Encryption not possible.
0x8D
Type II with CC-, ACC-, SN-
and PLCRC-field
Encryption type 1 for extended link layer is
supported (AES128/CTR).
0x8E
Type III with CC-, ACC-, M2-,
and A2-field
Encryption not possible. The fields M2 and A2 are
intended for destination address and are presently
ignored by the product.
0x8F
Typ IV with CC-, ACC-, M2-,
A2-, SN- and PLCRC-field
Encryption type 1 for extended link layer is
supported (AES128/CTR). The fields M2 and A2 are
intended for destination address and are presently
ignored by the product.
Table 8 Handled CI-fields for “extended link layer”
6.1.4.2.2 Handled CI-fields for application data
CI-Fält
Designation
Description
0x72
Normal data telegram with
long application header
Telegram with 12-byte header. Secondary address
for the corresponding virtualized meter on wired
M-Bus is taken from the ID-field in this header.
0x73
”Compact frame” data
telegram with ”long
application” header
Same as above.
0x6B
”Compact frame” format
telegram with ”long
application” header
Same as above.
0x6F
”Application error”-telegram
with ”long application”
header
Same as above.
0x75
”Alarm”-telegram with ”long
application” header
Same as above.
0x7A
Normal data telegram with
”short application” header
Telegram with 4-byte header. Secondary address
for the corresponding virtualized meter on wired
M-Bus is taken from the ID-field ”Link layer
header”.
0x7B
”Compact frame”
datatelegram with ”short
application” header
Same as above.
