CMeX50 Users Manual English
CMeX50 Users Manual English
page | 70 (89)
2017-10-13
Document id: 1090055 Version 1.5
5
0xnn
A-Field = Address of slave
6
0x51
CI-Field = Master to slave data send
7-14(15)
0x027C03746977nnnn
OR
0x02FC0374697700nnnn
Write wireless installation time
nnnn = 16-bit unsigned installation time in minutes
Valid interval: 0..9999
15(16)
0xnn
Checksum
16(17)
0x16
Stop character
6.3.17.2 Slave to master
Byte index
Data
Description
0
0xe5
Acknowledge
6.3.18 Start/stop installation mode
This command is used to start or stop an installation window.
6.3.18.1 Master to slave
Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x43 | 0x53 | 0x63 | 0x73
C-Field = SND_UD
5
0xnn
A-Field = Address of slave
6
0x51
CI-Field = Master to slave data send
7-14(15)
0x027C03746977nnnn
OR
0x02FC0374697700nnnn
Start/stop installation window
nnnn = 16 bit unsigned installation time in minutes.
Valid range: 0..9999
Setting nnnn to zero will stop current installation.
15(16)
0xnn
Checksum
16(17)
0x16
Stop character
6.3.18.2 Slave to master
Byte index
Data
Description
0
0xe5
Acknowledge
