5.7.2 Edit LCD contrast
Select menu choice 2. LCD contrast using Up/Down keys and press OK key.
This setting changes the contrast of the LCD display.
Change the LCD contrast of the product by using Up/Down keys and move the cursor using Right/Left
keys.
Accept the changes by pressing OK or cancel by pressing the ESC key.
5.7.3 Edit password
Select menu choice 3. Password using Up/Down keys and press OK key.
The password is used when a user is accessing the product using the LCD display.
Change the password of the product by using Up/Down keys and move the cursor using Right/Left keys.
Retype the password when asked.
Accept the changes by pressing OK or cancel by pressing the ESC key.
5.7.4 Edit Sleep time
Select menu choice 4. Sleep time using Up/Down keys and press OK key.
The sleep time is the time in minutes before the LCD display enters sleep mode and a new login is
requested.
Change the sleep time of the product by using Up/Down keys and move the cursor using Right/Left keys.
Accept the changes by pressing OK or cancel by pressing the ESC key.
5.7.5 Show system information
Select menu choice 5. System info using Up/Down keys and press OK key.
The system information page is used to show information about the product to the user.
Press the ESC key to exit the system information page.
5.7.6 Show radio status
Select menu choice 6. Radio status using Up/Down keys.
The radio status page is used to show status for the radio.
Name
Description
RF-Reset
Number of times the radio has been restarted because no telegram has
been received in 30 minutes.
L-Err S
Number of times the L-field has been less than 9 in mode S.
L-Err T
Number of times the L-field has been less than 9 in mode T.
L-Err Ca
Number of times the L-field has been less than 9 in mode Ca.
L-Err Cb
Number of times the L-field has been 128, 129 or less than 11 in mode Cb.
LC-Dec T
Number of times the L- and C-field has had invalid 4/6-coding in mode T.
F-Dec T
Number of times invalid 4/6-coding has been found in RX FIFO-interrupt.
E-Dec T
Number of times invalid 4/6-coding has been found in RX End-of-Packet-
interrupt.
H-Err Cx
Number of times other than 0x3D or 0xCD came after 0x54 in mode Cx.
C-Err S
Number of telegrams with at least one invalid CRC received in mode S
