Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x08
RSP_UD
5
0xnn
A-Field = Primary address of virtualized M-Bus
slave
6
0x72
Variable data respond, mode 1 = LSByte first
7-10
0xnnnnnnnn
Secondary address of virtualized M-Bus slave
11-12
0xnnnn
Manufacturer id of virtualized M-Bus slave
13
0xnn
Generation field of virtualized M-Bus slave
14
0xnn
Device type / medium of virtualized M-Bus slave
15
0xnn
Access number of virtualized M-Bus slave
16
0xnn
Status byte of virtualized M-Bus slave
0x00 = Ok (no error)
17-18
0x0000
Signature, 16 bit binary
Optional CMeX50 information depending DIF/VIF mode, see section 6.1.4 and 6.2.7
19..N
Wireless M-Bus slave payload data
N+1
0x0F or 0x1F
End of telegram
More data available: 0x1F
No more data available: 0x0F
N+2
0xnn
Checksum
N+3
0x16
Stop character
6.3.2.4.2 Virtualized M-Bus slave data with encapsulation in a container
Byte index
Data
Description
0
0x68
Start character 1
1
0xnn
L-Field 1
2
0xnn
L-Field 2
3
0x68
Start character 2
4
0x08
RSP_UD
5
0xnn
A-Field = Primary address of virtualized M-Bus
slave
6
0x72
Variable data respond, mode 1 = LSByte first
7-10
0xnnnnnnnn
Secondary address of virtualized M-Bus slave
11-12
0xnnnn
Manufacturer id of virtualized M-Bus slave
13
0xnn
Generation field of virtualized M-Bus slave
14
0xnn
Device type / medium of virtualized M-Bus slave
15
0xnn
Access number of virtualized M-Bus slave
16
0xnn
Status byte of virtualized M-Bus slave
