4 Perform a Test
4.8 Insulation 1.2/50
1
2
3
1 Generator
Select the Insulation test. The correct output of the generator will be illuminated.
2 EUT
The EUT must be unpowered during the insulation test. Otherwise the Generator can
be damaged.
3 Measurement Equipment
During the test, the voltage and current can be monitored with a current and voltage probe.
4.9 Calibration
The calibration is made without any EUT connected. Additional information for calibration is
also available in the calibration report.
