9 Technical Data
9.7 ADAPTER BOX RJ45-8L
max. DOW Level
16
1500 V
Dimension 22 cm x 7 cm x 3 cm
Weigth 0.2 kg
9.8 VERI1K EFT
Impedance 1000 Ω±2 %
DC Ratio
50 ΩDSO Input 1:2000
1 MΩDSO Input 1:1000 ±3 %
Tolerance of Insertion Loss
up to 100MHz ±0.5 dB
up to 400MHz ±3 dB
Max. Level 7100 V EFT- or Fast-DOW-Impulse
Max. average Spikes/s 350 @7100 V
Dimension 13.5 cm x 2.5 cm x 2.5 cm
Weight 0.1 kg
9.9 VERI01 OSI
Impedance 0.1 Ω±2 %
DC Ratio
50 ΩDSO Input 1:20
1 MΩDSO Input 1:10 ±2 %
Tolerance of Insertion Loss
up to 100MHz ±0.5 dB
up to 400MHz ±3 dB
Max. Level 6300 V Fast-DOW-Impulse
Max. average Spikes/s 500 @6300 V
Dimension 8.5 cm x 2.5 cm x 2.5 cm
Weight 0.1 kg
16
Limitation due to the pin spacig of the RJ45-Plug.
