9 Technical Data
9.5 CDN-DOW-DATA-HF
Standard IEC 61000-4-18:2019
IEC 60255-26:2013
Frequency 100 KHz ±10 %
1 MHz ±10 %
Number of data lines 4 lines / 2 pairs (10/100 MBit/s)
8 lines / 4 pairs (1 GBit/s)
Coupling
Common Mode 1 One pair to all other pairs (floating)
Common Mode 2 One pair to all other pairs (grounded over 0.5 µF)
Coupling capacitor 0.5 µF per line
Open Circuit
Level CDN Output
100 kHz 200 V - 4000 V ±10 %
1 MHz 200 V - 4000 V ±10 %
Rise time 75 ns ±20 %
Decaying
Peak5 to Peak1 >50 %
Peak10 to Peak1 <50 %
Short Circuit
Level CDN Output
100 kHz 1 A - 20 A ±20 %
1 MHz 1 A - 20 A ±20 %
Output Impedance 200 Ω
Line Inductance >1.5 mH
Operating Mode manual
EUT (for Power over Ethernet)
Voltage max. 60 V DC
Current max. 1 A per line
Dimension 30.5 cm x 23 cm x 11 cm
Weight 3.7 kg
